2P-20P Screw Terminal Block
2P-20P terminal block:
Rate voltage: 690VAC/1000VDC;
Rate current: 60A/690VAC,50A/1000VDC.
Product Specifications | |||||||||
Insulation material | PBT | Ambient temperature range | -40â...+90â | ||||||
Rated current/Voltage(DC) | Max.:50A/1000VDC | Storage temperature | -40â...+90â |
||||||
Rated current/Voltage(AC) | Max.:60A/690VAC | Connecting system | Lock connection | ||||||
Test voltage | 4kV(50Hz,Imin) | Rise in temperature | 30â | ||||||
Contact material | Copper,Tin plated | Nut cap locking force | 0.2-0.6Nm | ||||||
Flame class | UL94-V0 |
Application:
1.Solar inverter AC output or input;
2.Solar combiner box and distribution box;
3.Electrical car.
![]() |
