Solar Isolator Switch dc disconnector switch isolation switch

Solar Isolator Switch dc disconnector switch isolation switch

Product Details:

  • Product Type Other
  • Operating Temperature -40-+70 Celsius (oC)
  • Max Voltage 1500 Volt (V)
  • Output Voltage 1500 Volt (V)
  • Size 2P
  • Dimension(L*W*H) 65*45*78.5 Millimeter (mm)
  • Color Black
  • Supply Ability : 10000 Piece Per Month
10.00 - 20.00 USD ($)/Piece

Price And Quantity

  • 10.00 - 20.00 USD ($)/Piece
  • 1000 Piece

Product Specifications

  • 1500 Volt (V)
  • 2P
  • 65*45*78.5 Millimeter (mm)
  • Other
  • 1500 Volt (V)
  • -40-+70 Celsius (oC)
  • 5
  • Black

Trade Information

  • EXW
  • Telegraphic Transfer (T/T), Paypal
  • 10000 Piece Per Month
  • 15 Days
  • Yes
  • Contact us for information regarding our sample policy
  • Standard packing
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • All India
  • TUV

Product Description

Solar Isolator Switch Dc


Rated voltage:1000/1500V

Rated current:16/20/25/32A

Rated Heating current: 32A

Rated insulation voltage: 1500V

Rated impulse withstand current(1s):700A

Rated short circuit capacity: 1400A

Size(length*width*height):2P 65*45*78.5mm

                                           4P 65*45*98.5mm

                                           6P 65*45*118.5mm

Product polarity:2,4,6

Product connection capability: 16mm²

Min-Max M4 tightening torque:1.5-2.0

Panel install nut tightening torque:3-3.3

Installation method:Panel Type
