Waterproof BIPV Junction Box Solar Panel Junction Box With Diode Solar Module Junction Box

Waterproof BIPV Junction Box Solar Panel Junction Box With Diode Solar Module Junction Box

Product Details:

  • Product Type Other
  • Material PPE/TPV
  • Operating Temperature -40-+85 Celsius (oC)
  • Max System Voltage 1500 Volt (V)
  • Output Voltage 1500 Volt (V)
  • Color Black
  • Warranty 2
8.5 USD ($)/Piece
X

Waterproof BIPV Junction Box Solar Panel Junction Box With Diode Solar Module Junction Box Price And Quantity

  • 8.5 USD ($)/Piece
  • 100 Piece

Waterproof BIPV Junction Box Solar Panel Junction Box With Diode Solar Module Junction Box Product Specifications

  • -40-+85 Celsius (oC)
  • Other
  • 2
  • PPE/TPV
  • 1500 Volt (V)
  • Black
  • 1500 Volt (V)

Waterproof BIPV Junction Box Solar Panel Junction Box With Diode Solar Module Junction Box Trade Information

  • EXW
  • 10000 Piece Per Month
  • 15 Days
  • Yes
  • Contact us for information regarding our sample policy
  • Standard packing
  • All India
  • CE,TUV

Product Description

Solar Bipv Junction Boxï

The BIPV Product Description

Box Material: PPE/TPV

Rated current: 14A(Diode 20A/)/18A(Diode 25A)

Rated voltage: 1500VIEC

Test voltage: 8KV50HzImin

Typical contact resistance: 5mohm

Contact materialCopperTin: plated

Degree of protection: IP67(in potting)

Safety degree: II

Flame class: UL94V0

Ambient temperature range: -40ï...+85ï(IEC)

Suitable cable cross sections: 40mm

Diode NumberEach: 1PC

Upper limiting temperature: 110ï(IEC)

Range of cable gland(mm): OD55

Ribbons size(mm): 6(W)*02-04(T)

Connection of bus ribbons: Clamp
