PV 4.0 Diode Connector 4D1-4D3
  • Insulation material:PPE/PA;Over voltage category/Pollution degree:CATIII/2;
  • Rated current(Without diode):30A;Safety degree:II;
  • Rated current(With Diode):10A(Diode Rated Current 15A);Flame class:UL94-V0;
  • Rated voltage:1000VDC;Insertion force/Withdrawal force:less than 50N / more than 50N;
  • Test voltage:6kV(50Hz,Imin);Ambient temperature range:-40-+85(IEC);
  • Typical contact resistance:less than 0.25 mohm;Upper limiting temperature:110(IEC);
  • Contact material:Copper,Tin plated;Connecting system:Crimp connection;
  • Degree of protection:IP67;Nut cap locking force:1.5-1.8Nm.


Reliable Solar Array Protection

The 4D1 Solar Blocking Diode ensures your solar PV systems are safeguarded against reverse current flow, effectively protecting valuable solar panels from potential damage. Utilizing Schottky diode technology, it minimizes power loss for optimal efficiency, making it an essential component in solar installations regardless of scale or environment.


Built for Harsh Conditions

This connector boasts an IP67 waterproof rating and is manufactured from UV-resistant materials, ensuring resilience against outdoor exposure. Designed to withstand temperatures from -40C to +85C, the 4D1 Solar Blocking Diode remains reliable in extreme conditions, providing peace of mind for both residential and commercial solar array operators.


Simplified Installation and Maintenance-Free Operation

Delivered pre-assembled with a customizable cable and featuring an MC4-compatible male output, this diode connector can be easily integrated into existing solar systems. Its inline connection design and maintenance-free operation streamline the installation process, saving both time and labor.

FAQs of 4D1 Solar Blocking Diode Male Cable Type 1000VDC 10A IP67 Waterproof PV Diode Connectors:


Q: How is the 4D1 Solar Blocking Diode Male Cable Type connected in a PV system?

A: The 4D1 diode comes with a pre-assembled male cable type (MC4 compatible) which is designed for straightforward inline connection into solar PV wiring. Simply connect the MC4 male end into the corresponding female connector within your solar array to block reverse currents.

Q: What are the main benefits of using this blocking diode in a solar PV application?

A: Utilizing the 4D1 blocking diode ensures that reverse current does not flow back into your PV modules, preventing damage and enhancing overall system longevity. The Schottky diode ensures low power loss for high efficiency, and its waterproof, UV-resistant construction guarantees dependable outdoor performance.

Q: When should I use a blocking diode like the 4D1 in my solar system?

A: Blocking diodes are typically installed when there is a risk of reverse current flow, such as in PV arrays with battery storage or multiple strings. The 4D1 should be used when you need to protect panels from current traveling back into the array during low or no sunlight conditions.

Q: Where is this diode connector best suited for installation?

A: Thanks to its IP67 rating and UV resistant materials, the 4D1 is specifically developed for outdoor environments and is ideal for both rooftop and ground-mounted solar installations regardless of climate.

Q: What process should be followed for installing the 4D1 Solar Blocking Diode?

A: Installation involves connecting the pre-assembled cables male MC4-compatible end securely into the PV arrays matching connector. Ensure voltage is not present during installation and verify tight, waterproof seals for optimal protection.

Q: Is any maintenance required after installation?

A: No maintenance is needed post-installation. The 4D1 diode is engineered to be maintenance-free, contributing to its long service life and hassle-free operation.
